| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | calibration certificate (cost additional) |
| Model Number: | HCMP50 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | plywood |
| Delivery Time: | 45 days |
| Payment Terms: | T/T |
| Supply Ability: | 1 set /month |
| Product Name: | Motor Performance Test System | Standard: | IEC 60034-1 |
|---|---|---|---|
| Application: | Perform The Performance Characteristics Of Motor | Test Benchs: | 2 |
| Test Stations: | 3 | Test Samples: | Single-phase Motor, 3-phase Motor |
| Dynamometer: | 1.7 N.m, 6.2 N.m And 50 N.m | Testing Methods: | Manual And Automatic |
| Highlight: | IEC 60034 Motor Performance Test Lab,Automatic Motor Performance Test Lab |
||
IEC 60034 Motor Performance Test Lab With Manual And Automatic Testing
Standard:
IEC 60034-1 Rotating electrical machines-Part 1: Rating and performance.
Application:
Mainly used to measure motor speed, torque, output power, voltage, current, input power, frequency, and efficiency. Appliance Performance Test Lab
Main testing items:
In addition to all enterprise testing items, following functions are included:
| 1 | DC resistance test under cold and thermal status. |
| 2 | No-load test: Acquire no-load characteristics curves through test, calculate the no-load current, no-load power and iron loss and mechanical loss. |
| 3 | Locked-rotor test: Acquire the locked-rotor characteristics curve through test, calculate locked-rotor torque and current. |
| 4 | Load test: This test is to acquire the load characteristics curve and calculate the motor parameters after modification. Appliance Performance Test Lab |
| 5 | Temperature rise test: Use resistance thermometry method to calculate the motor temperature rise. During test, motor winding temperature, core temperature and others are monitored by temperature detection apparatus. |
| 6 | T-N curve drawing: Draw T-N curve of induction motor in a real time and automatically test the maximum torque and minimum torque as well as the rotation speed of single-phase induction motor upon disconnection of centrifugal switch. |
