| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Quality delivery report |
| Model Number: | HJ139 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood |
| Delivery Time: | 90 days |
| Payment Terms: | T/T |
| Supply Ability: | 2 Sets per month |
| Vacuum Chamber: | 1 Set | Energy Consumption: | 15KW |
|---|---|---|---|
| Production Takt: | 5min/ Piece | Detection Precision: | 1.0E-7mbar*L/s |
| Helium Recovery: | It Is Equipped With Helium Recovery Device To Reuse Helium Gas | Weight: | 1000KG |
| Control Mode: | Manual/Automatic | Name: | Helium Leak Testing Equipment For EV Power Battery |
| Test Medium: | Helium | Type: | Leak Testing Equipment |
| Highlight: | 15KW Helium Leak Testing Equipment,Automatic Helium Leak Testing Equipment |
||
Helium Leak Testing Equipment for EV Power Battery Chamber Type
Product Introduction of Helium Leak Testing Equipment:
This product is a power battery helium detector, which mainly includes battery scanning code, loading, leakage detection, evacuation, helium filling, helium inspection, and other processes. Then the helium signal in the leak detection chamber is detected by the helium leak detector, which can judge the leakage of the workpiece quickly and accurately with high precision. The equipment can be compatible with different sizes, but the fixture needs to be replaced.
Technical parameters of Helium Leak Testing Equipment:
| NO. | Project | Parameter |
| 1 | Alarm leakage rate | 5E-5 mbar.l/sec |
| 2 | Energy consumption | 15KW |
| 3 | Vacuum chamber | 1 set |
| 4 | Production speed | 5min/ piece |
| 5 | Minimum detection accuracy | 1.0E-7mbar*L/S |
| 6 | Helium-filled pressure | 0-0.5Mpa |
| 7 | Size | ≤2500mm*2500mm*2200mm |
| 8 | Weight | 1000KG |
| 9 | Operating voltage | 380V |
Product details picture:
