| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration certificate(cost additional) |
| Model Number: | GW-2 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood |
| Delivery Time: | 30 working days |
| Payment Terms: | T/T |
| Supply Ability: | 5 Sets per month |
| Name: | Glow Wire Test Apparatus | Standard: | IEC 60695 |
|---|---|---|---|
| Application: | Glow Wire Test | Control Mode Of Operation: | PLC Control |
| Glowing Filament: | Ф4mm ± 0.04mm | Maximum Depth Of Heating: | 7mm ± 0.5mm |
| Testing Time: | 30s±1s | Thermocouple: | Temperature Resistance 1100° |
| Highlight: | PLC Control Flammability Testing Equipment,IEC 60695 Flammability Testing Equipment |
||
Flammability Testing Equipment For Glow Wire Test In Accordance With IEC 60695
Standard of Flammability Testing Equipment:
The glow wire test is a physical thermal testing test method for plastics. It belongs to the IEC 60695 series of standards "Tests for the assessment of fire hazard" and includes the standard parts 2-10, 2-11, 2-12, and 2-13.
IEC 60695-2-10 – Glow wire test equipment and general test method.
IEC 60695-2-11 – Tests with the glow wire for flammability of end products (GWEPT).
IEC 60695-2-12 – Testing with glow wire for flammability of materials (GWFI).
IEC 60695-2-13 – Tests with the glow wire for the flammability of materials (GWIT).
Application of Glow Wire Test Machine:
Glow wire testing is an example of the indirect flame method. Test results from applying these methods provide a way to compare the materials' tendency to resist ignition, self-extinguish flames (should ignition occur), and ability to not spread or propagate fire via dripping.
Parameters of Glow Wire Test Apparatus:
|
ParametersModel |
GW-2(Touch screen) |
| Working voltage | 220V /50Hz |
| Control operation mode | PLC control, 7 inch color touch screen operation, with infrared remote control |
| Glowing filament | Ф4mm ± 0.04mm (> 77 % Ni/20 ± 1 % Cr) special standard ring shape,horizontal standing |
| Specimen pressure on glowing filament | 0.95N±0.1N |
| Maximum depth of heating | 7mm ± 0.5mm |
| Specimen movement speed | 10mm /s ～ 25mm /s |
| Temperature calibration | Calibration temperature:960°±10°C, the hot wire by electric heating |
| Thermocouple: RS imported 1mm armour nickel-chromium/nickel/ nickel aluminum K-Thermocouple, temperature resistance 1100° | |
| Silver foil: purity 99.8%, area :2m², thickness:0.06mm | |
| Tray | A layer of silk paper (12~30g/m³) is covered on the 10mm thick pine board, with a distance of 200±5mm below the test sample |
| Test chamber | >0.5 cube,sample distance from the inside of the box is greater than 100mm, black yogon background,background illuminance ≤ 20Lx,with exhaust fan |
| Testing time | 30s±1s |
| Test procedure | The test sample is driven by the car and automatic run, the car will return automatically after glow-wire entered the test sample of 7mm |
| Lighting | Equip with lighting in the test chamber, with control |
| Dimension | 1100*550*1200mm, 140kg |
Product detail picture:
