| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration certificate(cost additional) |
| Model Number: | LT-3 |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood |
| Delivery Time: | 90 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 set per month |
| Timing Device: | 9999X0.1S Resolution | Electrode Material: | Platinum |
|---|---|---|---|
| Electrode Specifications: | 5mm*2mm | Electrode Spacing: | 4±0.1mm |
| Electrode Pressure: | 1±0.05 N | Electrode Angle: | 60° |
| Short Circuit Voltage Drop: | 8% MAX | Short-circuit Current: | 1±0.1A Accuracy: 1% |
| Highlight: | Tracking Flammability Testing Equipment,Platinum Electrode Flammability Testing Equipment,0.5 M3 Flammability Testing Equipment |
||
Working Volume >0.5 M³ Tracking Test Equipment For Flammability Testing Equipment
Product Introduction with Flammability Testing Equipment:
The test machine is designed and manufactured according to the requirements of the relevant standards, such as IEC 60112, IEC60695 and etc. It is used for determination of the relative resistance to tracking performance that solid electrical insulating material under the action of an electric field, when the surface exposed to water containing impurities.
If electrical products affected by moisture and impurities environmental, leakage may be caused on the insulation between different polarity live parts or live parts and grounded metal, the generated arc will cause short circuit or electrical erosion due to discharge, even cause fire. The tracking test is a destructive test to insulating material simulating the above situation, to measure and assess the relative resistance to tracking when the insulator is in the effect of electric and impurities in water-containing.
Product Features with Flammability Testing Equipment:
This equipment adopts advanced PLC control system, touch-screen humanized button operating device, high quality materials and professional technology, which make itself has excellent quality, stable and durable performance and beautiful appearance. In addition, automatic drip timing device, accurate electrode pressure sensor display, simple operation and high accuracy improve the efficiency of the test and make our equipment takes a leading position in similar products.
Product Parameters with Flammability Testing Equipment:
| Timing device | 9999X0.1S Resolution | Drip interval | Adjustable | ||
| Electrode material | Platinum | The height of the drip | 30～40mm | ||
| Electrode specifications | 5mm*2mm | Drip delay | 0.2S (solenoid valve open time) | ||
| Electrode spacing | 4±0.1mm | Drip size | 45 ~ 50 drops / cm3 | ||
| Electrode pressure | 1±0.05 N | Delay electric circuit | 2 ± 0.1S (at 0.5A) | ||
| Electrode angle | 60° | Test voltage range |
0～600V Accuracy:1.5% |
||
| Short circuit voltage drop | 8% MAX | Electrical parameters | 1.5KW/220VAC/50Hz | ||
| Short-circuit current | 1±0.1A Accuracy: 1% | Working volume | > 0.5 M³ | ||
| Environmental requirements | 0 ~ 40 ℃ / ≤ 80% relative humidity | ||||
| Standards | IEC60112, UL746A, IEC60695, ASTMD3638. | ||||
Product Image with Flammability Testing Equipment:
Our advantage service:
We have our own developing and designing team, which ensure our own technological and innovative products for customers.
For any customers who have new idea about some products, just let us know, we can according to your idea provide a unique design of the products.
Technical support:
All our workers are experienced and skilled.
After sale service:
Our working team and sales teams can guarantee a fast and high efficiency after-sale service for our product sold to everywhere of the global.
About Us:
Guangzhou Hongce Equipment Co., Ltd is a leading company in inspection equipment industry, established in 2003 and located in Guangdong, China. Our company introduced advanced equipment, combined with the most advanced technology production processes, strict quality control system to control the entire process of production. The company combined with a number of high-tech management personnel and advanced equipment, and together with the modern management, computer design and control, our products has reached the international advanced level. The company set R&D design, production, sales as one, specializing in producing electric wire inspection equipment of plug and socket, mechanical robustness testing equipment of electronics, inspection equipment of electronics’ on-fire danger, testing indicator of anti-electric shock and solid objects' entry, general inspection equipment, and other non-standard testing equipment. Our products enhance good selling at home and abroad, and have established supply relationships with a number of well-known companies.
