| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration Certificate(cost additional) |
| Model Number: | HO6502 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Standard export packing |
| Delivery Time: | 30 days |
| Payment Terms: | T/T, PayPal, D/A, Western Union, MoneyGram, L/C |
| Supply Ability: | 10 Sets per month |
| Type Of Connector: | 0.2A, 2.5A,6A And 10A | Max. Withdrawal Forces: | 50N,60N |
|---|---|---|---|
| Min. Withdrawal Forces: | 1.5N,2N | Standard: | IEC60320-1 Clause 16 Figure12 |
| Maximum Multi-pin Gauge Maximum: | 60 | Warranty Period: | 1 Year |
| Minimum Multi-pin Gauge Maximum: | 50 | ||
| Highlight: | Tensile Strength Testing Machine,Withdrawal Forces Coupler Withdrawal Testing Apparatus,60N Coupler Withdrawal Testing Apparatus |
||
Maximum withdrawal forces 60N Coupler Withdrawal Testing Apparatus HO6502 with Tensile Strength Testing Machine
Standardwith Tensile Strength Testing Machine:
Confirm to the IEC60320-1 clause 16 figure12 standard requirement.
Application with Tensile Strength Testing Machine:
This device is mainly used to ascertain the maximum force necessary to withdraw the connector from the appliance inlet and the minimum force necessary to withdraw a single pin gauge from the appliance inlet, it can also for testing connectors for hot conditions and those for very hot conditions.
Product Feature with Tensile Strength Testing Machine:This device consists of a control cabinet, mounting plate, heating device, instrument input socket (standard equip with 10A for testing connectors for hot conditions, 10A and 16A for very hot conditions) hook, and the principle weight,supplementary weight.
.
Product Parameters with Tensile Strength Testing Machine:
1. Power supply:220V,50/60HZ.
2. Table 3-Maximum and minimum withdrawal forces
| Type of connector |
Withdrawal forces N |
|
| Multi-pin gauge maximum | Single-pin minimum | |
| 0.2A, 2.5A,6A and 10A | 50 | 1.5 |
| 16A | 60 | 2 |
q
3. Maximum withdrawal forces
| Maximum withdrawal forces | Principle weight | Supplementary weight |
| 50N | 45N(with hook) | 5N |
| 60N | 45N(with hook)+4N+5N | 6N |
| Note: The weight hook are included in the weight of 45N. | ||
4. Minimum withdrawal forces
| Minimum withdrawal forces | Weight |
| 1.5N |
1.5N weight and 10Alive wire or ground wire of the single-pin |
| 2N |
2N weight and16Alive wire or ground wire of the single-pin |
| Note: The weight of the single-pin is included in the corresponding weight | |
5.The heating gauge of 10A for testing connectors for hot conditions, 10A and 16A for very hot conditions, others are test gauge in cold conditions, test gauges are optional.
Product Image with Tensile Strength Testing Machine:
