| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Product factory certificate |
| Model Number: | HC174 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood |
| Delivery Time: | 60 days |
| Payment Terms: | T/T |
| Supply Ability: | 1 Sets per 2 month |
| Detection Workpiece: | Relay | Number Of Station: | 2 |
|---|---|---|---|
| Ultimate Vacuum Degree: | ≤0.4Mpa | Color: | Gray-blue |
| Size: | 1200mm*1000mm*1700mm | Weight: | 1000kg |
| Screen: | Touch Screen | Protective Device: | Safety Grating |
| Highlight: | High Vacuum Exhaust Table Testing Equipment,2 Station Exhaust Table Testing Equipment |
||
High Voltage DC Relay Hydrogen Leakage Detection Equipment
Product Description:
The high vacuum exhaust table for high voltage DC relay is mainly used for vacuuming, leak detection, gas filling and sealing of high voltage DC relay series product components. The equipment uses a molecular pump as the main pump for vacuuming and is equipped with 5 station exhaust nozzles. It can work in a single or multiple station combination, realizing a series of automated operations from manual placement of relays to locking and sealing, pre-evacuation, high vacuum exhaust, gas filling and leak detection, sealing and leak detection.
Working principle of the product:
The testing equipment consists of a workpiece sealing system, a vacuum system, an inflation system, a cutting system and an electrical system, which can automatically inflate and seal the workpiece.
Product features:
High degree of automation: The high vacuum exhaust table of the high-voltage DC relay adopts a semi-automatic design. Through the coordination of system software and hardware, it can realize functions such as safety protection, interlocking protection, and fault alarm to achieve the purpose of convenient operation and maintenance.
High production efficiency: The equipment is generally set up in a multi-station form to improve production efficiency. Each station can be operated simultaneously or independently, making the production process more flexible and efficient.
Advanced technical indicators: The equipment uses a molecular pump as the main pump for exhaust, with 5 station exhaust nozzles, and the stations can work individually or in any combination of multiple stations. The operation process is automated, including manual placement of relays, locking and sealing, pre-extraction, high vacuum exhaust, inflation leak detection, sealing and leak detection, etc.
High safety: The equipment not only ensures product quality, but also focuses on improving production efficiency. Through various reliable interlocking and protection functions, the safety of the operation process is ensured.
Technical parameters:
| Detection workpiece | relay |
| Number of stations | 2 |
| Ultimate vacuum degree | ≤0.4Mpa |
| Color | gray-blue |
| Accessories | waste collection box |
| Control system | PLC |
Product details:
