| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Third part calibration certificate(cost additional) |
| Model Number: | HC9922 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Plywood |
| Delivery Time: | 30 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 set per month |
| Product Name: | Rotating Barrel Test Apparatus | Barrel Number: | One Or Two |
|---|---|---|---|
| Speed Of Rotation: | 5 R/min | Falling Times: | 10 Times/min |
| Height Of The Falls: | 500mm | Application: | Appliance Mechanical Strength Test |
| Standard: | IEC 60335-1, IEC 60068-2-31 | Test Time: | 100 Or 50 Times |
| Highlight: | 100kg Load Drop Test Solution,Smart Home Appliance Drop Test Solution,IEC 60068-2-31 Drop Test Solution |
||
When you hold a well-designed home appliance, have you ever thought about the various tests it may go through from the production line to the hands of consumers? The roller drop tester is born to protect this quality promise. As the "safety guard" in the field of home appliance testing, we are well aware that behind each device is the company's insistence on quality and the expectation of durability of tens of millions of families. By simulating real drop scenarios, we help you foresee risks in advance, so that each product can enter thousands of households in the most perfect posture.
IEC 60335-1: 2020 Household and similar electrical appliances – Safety – Part 1: General requirements clause 21.1;
IEC 60068-2-31: 2008 Environmental testing – Part 2-31: Tests – Test Ec: Rough handling shocks, primarily for equipment-type specimens clause 5.3 and Annex A;
Design concept of letting technology convey warmth
Precisely guard every inch of quality
±0.5° angle adjustment accuracy, can simulate 5°-90° multi-dimensional drop trajectory, and carefully detect each vulnerable contact point
Understandable operating temperature
Number calculator, data visualization, so that technical parameters are no longer cold and difficult to understand
New proposition for green testing
Energy-saving drive system reduces energy consumption by 30%, and each test is a commitment to sustainable development
Reliability precipitated by time
10,000 hours of fatigue test, witnessing the years of quality commitment
| Model | HC9922 |
| Power Supply | 220V, 50Hz |
| Speed of rotation | 5 r/min |
| Falling times | 10 times/min |
| Counter | 0~9999 |
| Material | The body of the rotating barrek is of sheet of 1,5 mm thickness. The smooth,rigid, steel test surface at each end, 3 mm in thickness, is backed by wood of between 10 mm and 19 mm thickness. |
| Height | 500 mm |
We understand that every investment you make in testing equipment is about trust:
✅ 12-month core component warranty
✅ Global warranty service network covers 68 countries
✅ 7×24h remote technical support for immediate response
✅ Lifetime software upgrade service
