| Place of Origin: | Chnia |
| Brand Name: | HongCe |
| Certification: | Third part calibration certificate(cost additional) |
| Model Number: | HC9910B |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Plywood |
| Delivery Time: | 30 days |
| Payment Terms: | T/T |
| Supply Ability: | 20 set per month |
| Test Station: | 6 Stations | Test Current: | 0-1000A Adjustable |
|---|---|---|---|
| Test Voltage: | 5V, 12V, 24V, 48V | Temperature: | 0-150°C |
| Test Object: | Circuit Board | Standard: | IEC60884-1, VDE0620, UL |
| Product Name: | Temperature Rising Tester | Warranty: | 1 Year |
| Highlight: | IEC 60884-1 Plug Socket Tester,1000A Plug Socket Tester,6 Stations Temperature Rising Tester |
||
IEC60884-1 Temperature Rising Tester - Plug Socket Tester, 0-1000A Test Current
Product Introduction:
This device is in accordance with IEC60884-1 Fig 44 Clause 19 of the temperature rise to design and manufacture, it is mainly used to test the plug device and its accessories around, such as dimmers, fuses, switches, power regulators, etc., and it cannot reach excessive temperatures during normal use. This device adopts a high-precision digital meter, sensor signal input with 6 work stations, over-temperature and overload protection with voice prompts, strong applicability and stable performance Plug Socket Tester
Standard: IEC 60884-1 2013 clause 19, IEC 60998.1, VDE0620
Application: This device is use for test the temperature rise under normal operation of electrical appliances.
Test sample: Household plugs and sockets Plug Socket Tester
Feature: External type, thermocouple wire directly connected to the sample
Parameters:
| Item | HC9910B |
| Working station | 6 |
| Testing current | 50-1000A is adjustable |
| Testing voltage | 5V,12V,24V,48V |
| Timer | 0-9999s is adjustable, digital display |
| Temperature measuring meter | 0-150℃ digital display |
| Power supply | 220V,50HZ |
| standard | UL |
| Test object | circuit board |
| Sizes of the wire (single copper core) | Max. Load Current |
| 1.5mm² | 20A |
| 2.5mm² | 28A |
| 4mm² | 38A |
| 6mm² | 48A |
| 10mm² | 65A |
| 16mm² | 88A |
| 25mm² | 113A |
| 50mm² | 142A |
| 70mm² | 171A |
| 95mm² | 218A |
| 120mm² | 265A |
| 150mm² | 305A |
| 185mm² | 355A |
| 240mm² | 410A |
| 300mm² | 490A |
| 400mm² | 560A |
| 500mm² | 650A |
| 630mm² | 750A |
| 2.5mm² | 880A |
| 800mm² | 1100A |
